[Book Notes] System Design Interview — An Insider’s Guide (Volume 2)

A must-read when jobs in tech are at risk.

Image Source: Amazon.com

The following contents are my takeaways from Alex Xu and Sahn Lam’s book¹. Reading the original book is highly recommended for those who want to ace system design interviews.

System Design Interview Books: Volume 1 vs Volume 2

Chapter 1. Proximity Service

• Functional requirements:
  - Return all businesses based on a user’s location and a specified radius.
  - View details of a business.
  - Business administration operations, which may take effect the next day.
• High-level design:
  - Location-based service.
  - Business service (CRUD operations).
• Use a relational database, such as MySQL, for the read-heavy business data, and set up sharding and primary-secondary replication.
• The evenly divided grid doesn’t work well because the distribution of business is not even.
• Geospatial indexing:
  - Geohash: a 1D string that recursively subdivides the world into smaller and smaller grids with each additional bit.
  - Quadtree: an in-memory data structure that recursively subdivides a plane into four quadrants.
  - Google S2: mapping a sphere to a 1D index based on the Hilbert curve, on which two points are close if they are close in 2D space.
• For 200 million businesses, the quadtree can easily fit in the working set of a single server and just takes a few minutes to build.
• Geohash is easier to update on location change, but a quadtree can dynamically adjust the grid size based on population density.
• Use a Redis cluster to cache:
  - The business info by id.
  - The business ids in a grid by geohash.

Chapter 2. Nearby Friends

• Functional requirements:
  - Fetch nearby friends within a radius.
  - Refresh the user location every 30 seconds.
• High-level design:
  - RESTful API servers for updating user profiles and friendships.
  - WebSocket servers, which maintain persistent connections with active users.
  - Redis Pub/Sub servers, which provide lightweight channels for propagating location updates to WebSocket connection handlers.
  - Redis cluster, which caches user locations (latitude, longitude, timestamp) with TTLs.
  - Cassandra for location history sharded by user id.
• The load balancer should be able to auto-scale stateful WebSocket servers.
• The location cache should be sharded on user id for the traffic of location updates is high.
• Creating a new Redis pub/sub channel is lightweight, so at client initialization time a user can subscribe to all the friends regardless of whether they are active or not.
• Use consistent hashing to shard Redis Pub/Sub servers, and use ZooKeeper for service discovery.
• Pub/Sub servers are stateful due to the subscriber list of each channel, and thus take some overhead to scale out.

Chapter 3. Google Maps

• Features:
  - User location update.
  - Navigation service, including ETA.
  - Real-time map rendering.
• The mobile client should use as little data and battery as possible.
• Geocoding is the process of converting addresses to geographic coordinates.
• Geocoding info could be stored in Redis since it’s read frequently but written infrequently.
• Hierarchical routing tiles:
  - Local roads.
  - Arterial roads connecting districts.
  - Major highways connecting cities.
• Routing tiles could be stored in an object storage, such as S3.
• Location history should be batched before being sent to the server. Even so, it would be good to choose a database optimized for write throughput, such as Cassandra.
• User location data is also logged into Kafka, where it could be consumed by other services, such as for traffic monitoring and for personalization.
• Use tiles of different resolutions for map rendering of different zoom levels. These tiles should be pre-generated and be cached on a CDN.
• The advantages of a vector map over a rasterized map:
  - Better chances for compression.
  - Better zooming experience.

Chapter 4. Distributed Message Queue

• Additional features:
  - Long data retention.
  - Repeated consumption.
  - In-order delivery (for each partition).
  - Configurable data delivery semantics.
• Support two messaging models:
  - Publish-subscribe, which is implemented by topics.
  - Point-to-point, which is supported by consumer groups.
• A topic is divided into partitions, and a single partition can only be consumed by one consumer in the same group.
• An optional key in the message can be used to determine the partition.
• Storage includes:
  - Messages (on brokers’ local disks).
  - Consumer states (in ZooKeeper).
  - Topic metadata (in ZooKeeper).
• A coordination service (e.g. ZooKeeper) is used for:
  - Service discovery (which brokers are active).
  - Leader election (which broker is the active controller).
• Persist messages as WAL log files on disk to take advantage of the sequential access pattern.
• Wrap the routing layer into the producer to:
  - Minimize the number of network hops.
  - Batch messages in a single request.
• Latency-throughput trade-off: use a large batch size for high throughput and a small batch size for low latency.
• Use the pull model so that:
  - Consumers control the consumption rate.
  - It enables aggressive batching of data.
• For each consumer group, one of the brokers is assigned as the coordinator of the group for consumer rebalancing.
• To rebalance a consumer group, the coordinator elects one of the consumers as the leader and asks it to generate a partition dispatch plan, which will then be forwarded to each group member.
• A partition is replicated on multiple brokers and consumers only read from the leader replica.
• One of the brokers in the cluster is elected as the active controller for maintaining the leader/follower relationship for all the partitions in the topic metadata.
• Provide an acknowledgement setting (e.g. ACK=ALL) for trade-offs between performance and durability.
• Decommissioned partitions can only be removed after the retention period.
• For message filtering:
  - Filter messages on the broker side to avoid unnecessary traffic.
  - Attach tags to the metadata of each message so that brokers don’t need to decrypt or deserialize the payload.

[Paper Notes] Kafka: a Distributed Messaging System for Log Processing

Chapter 5. Metrics Monitoring and Alerting System

• Requirements:
  - Operational system metrics both at the node level and at the service level.
  - 1 year data retention.
  - Rolled up to 1 min resolution after 7 days.
  - Rolled up to 1 hour resolution after 30 days.
  - Multiple alert channels.
• Workload pattern:
  - Constant heavy write load.
  - Spiky read load.
• Five components:
  - Data collection.
  - Data transmission, which updates the TSDB.
  - Data storage (TSDB).
  - Alerting, which queries the TSDB.
  - Visualization, which queries the TSDB.
• A time series can be uniquely identified by its name, and optionally by a set of labels.
• Use an industrial-scale time-series database (TSDB) as storage, such as InfluxDB or Prometheus. They have features like caching, indexing and expressive query languages, which could obviate the need of a standalone query service.
• The pull model for data collection:
  - A metrics collector regularly pulls metrics from sources via HTTP.
  - Use ZooKeeper to maintain configurations of active sources.
  - Use consistent hashing for service partitioning among collectors.
  - Metrics can be viewed at any time for debugging purposes.
• The push model for data collection:
  - The collection agent at each source sends metrics to the metrics collector.
  - The collection agent may aggregate and buffer metrics before sending them.
  - The collectors could be organized as an auto-scaling group behind a load balancer.
  - Short-lived batch jobs can only use the push model.
• Three places for data aggregation:
  - The collection agent at each source.
  - The metrics collectors, which write the TSDB.
  - The TSDB readers.
• Use Kafka to buffer data and to decouple data collection from data processing, which ingests metrics into the TSDB.
• Set up an alert manager to:
  - Poll the TSDB or the query service.
  - Filter, merge and dedupe alerts.

Palo Alto, November 10, 2022

Chapter 6. Ad Click Event Aggregation

• Requirements:
  - Aggregate the number of clicks of an ad in the past M minutes.
  - Return the top K most clicked ads in the past M minutes.
  - Support data filtering by different attributes.
  - Correctness must be guaranteed.
  - End-to-end latency should be a few minutes at most.
• Store both the raw data and the aggregated data, and use Cassandra for the write-heavy workload.
• Use two Kafka instances to:
  - Decouple the log watcher and the services that persist or aggregate the raw data.
  - Provide end-to-end exactly-once semantics for delivering the aggregated data.
• Use the MapReduce framework for the aggregation service, which consumes the raw data from the first Kafka and produces the aggregated data in the second Kafka.
• Pre-define filtering criteria and aggregate data based on them.
• The Lambda architecture maintains the batch and stream processing paths separately, whereas the Kappa architecture combines them into one.
• Two places to generate timestamps for aggregation:
  - The event time on the client side, which is accurate but could be skewed.
  - The processing time on the server side, which can be delayed.
• How to handle delayed events when the event time is used?
  - Watermark: extend each aggregation window by 15 seconds, which improves data accuracy but increases overall latency.
  - End-of-day reconciliation.
• The aggregation service peforms a single distributed transaction to:
  - Send data to the downstream Kafka (with an ACK).
  - Record the offset in an external storage, such as HDFS.

Chapter 7. Hotel Reservation System

• Functional requirements:
  - View hotels and rooms.
  - Reserve a hotel room.
  - Add/delete/update a hotel room.
  - Support overbooking.
• Non-functional requirements:
  - Support high concurrency.
  - Moderate latency (a few seconds for reservation).
• Choose a relational database for the read-heavy workload and ACID properties.
• Include an idempotency key in the API for making reservations to avoid double booking.
• Use the microservice architecture and use remote procedure calls for inter-service communication.
• Keep a pre-populated room type inventory (for 2 years ahead) to support reservations by room type (instead of by room id).
• Concurrency control:
  - Pessimistic locking is prone to deadlocks and tends to have bad performance.
  - Optimistic locking is usually faster but performance dramatically drops when contention is heavy.
• How to scale up?
  - Shard the database by hotel since most queries need to filter by it.
  - Cache inventory information (aggregates) in Redis to reduce database load and improve read performance.
• Use the same service to manage reservations and the inventory to avoid data consistency issues that require 2PC or Saga.

Chapter 8. Distributed Email Service

• The traditional mail sending path:
  - Sender client =>
  - Sender SMTP server =>
  - Receiver SMTP server =>
  - Receiver mail server storage =>
  - Receiver IMAP/POP server =>
  - Receiver client.
• The proposed path:
  - Sender client =>
  - (LB =>) Web server =>
  - Outgoing queue =>
  - Sender-side SMTP worker =>
  - (LB =>) Receiver-side SMTP server =>
  - Incoming queue =>
  - Mail processing workers =>
  - WebSocket-based real-time servers =>
  - Receiver client (if online) and storage.
• Storage consists of:
  - Metadata DB (NoSQL with denormalization).
  - Attachment store (Amazon S3).
  - Distributed cache (Redis).
  - Search store (Elasticsearch).
• Kafka is used to decouple services that trigger reindexing and services that actually perform reindexing.

Chapter 9. S3-like Object Storage

• Three types of storage:
  - Block storage (e.g. HDD, SSD).
  - File storage, which usually has a hierarchical directory structure.
  - Object storage, which stores all data as objects in a flat structure.
• Characteristics of object storage:
  - Highly durable.
  - Vastly scalable.
  - Low cost.
  - Low performance.
  - Mainly for archival and backup.
• Functional requirements:
  - Bucket creation.
  - Object uploading and downloading.
  - Object versioning.
  - Listing objects in a bucket.
• Separate services for mutable metadata and immutable object data.
• Life of a read request:
  - The load balancer forwards the request to the API service.
  - The API service performs authentication and authorization.
  - The API service queries the metadata service.
  - The API service queries the storage service.
  - A response is sent back to the client.
• Components of the data store:
  - The stateless data routing service, which serves user requests.
  - The highly-reliable placement service, which maintains a virtual cluster map and monitors data nodes.
  - The data nodes with synchronous replication.
• Problems with too many small files:
  - Internal fragmentation.
  - It may exceed the system’s i-node capacity.
• Append multiple (small) objects into a large file and serialize writes to the same file.
• Multipart upload: slice a large object into smaller parts and upload them independently to the object store.
• Maintain the local object location info in SQLite at each data node.
• Two ways to achieve data redundancy:
  - Replication, which entails no computation or tail latency.
  - Erasure coding, which achieves higher durability with less storage.
• Use checksums to check against data corruption of files.
• Shard the object metadata by the combination of the bucket name and the object name.
• Support pagination of bucket listing by materializing the listing data in a separate table sharded by bucket_id.
• Add an object_version column to support object versioning.

Sunnyvale, November 12, 2022

Chapter 10. Real-time Gaming Leaderboard

• Functional requirements:
  - Display top 10 players.
  - Show a specific user’s rank along with the four players above and below her.
• The client directly queries the leaderboard but updates scores only through the game service.
• If fan-out on score updates (e.g. notification) is needed, use a message broker to connect the game service and the leaderboard service.
• Store user profiles in one MySQL table and cache hot ones in Redis.
• Store scores in another table and use a Redis sorted set to index users’ ranks.
• A sorted set is implemented by a hash table (user -> score) and a skip list (score -> user).
• Use AWS API Gateway and AWS Lambda to auto-scale the service.
• The score data can be partitioned by either the score range or the user key.
• Limitation of partitioning by score range:
  - Score distribution needs to be known a-priori to make load balanced.
• Limitations of partitioning by user key:
  - Determining a user’s rank is not straightforward.
  - Tail latency amplification and more response traffic for top-k queries.
• An alternative to MySQL + Redis is AWS DynamoDB with a global secondary index on scores.
• More partitions balances load better but complicates scatter-gather queries.

Chapter 11. Payment System

• The focus is on how to correctly handle payment transactions, rather than aiming for high throughput.
• The payment flow consists of a pay-in flow (buyer -> e-commerce) and a pay-out flow (e-commerce -> seller).
• A payment event may contain several payment orders.
• In the pay-in flow, the payment service:
  - Accepts payment events and performs risk checks.
  - Sends payment orders to the payment executor.
  - Updates the wallet for a seller upon success of executing an order.
  - Updates the double-entry ledger.
• Keep numbers in string format during transmission and storage to ensure precision.
• Payment Service Provider (PSP) integration:
  - The payment executor sends a payment registration request with a UUID called nonce.
  - The PSP returns a token, which is the UUID of the payment order on the PSP side and is persisted by the payment executor.
  - The client displays a PSP-hosted payment page.
  - The web page is then redirected to the redirect URL set by the payment system based on the payment status returned by the PSP.
  - Asynchronously, the PSP returns the payment status to the payment executor via a webhook.
• Reconciliation is a practice that periodically compares the states among related services in order to verify that they are in agreement.
• Put a failed payment to either the retry queue or the dead letter queue.
• Implementation of exact-once delivery:
  - Ensure at-least-once using retries.
  - Ensure at-most-once using idempotency checks.

Chapter 12. Digital Wallet

• The functional requirement is to provide cross-wallet balance transfer.
• It takes thousands of DB nodes to support millions of TPS.
• Distributed transaction:
  - X/Open XA is a standard to coordinate heterogeneous database to achieve 2PC.
  - 2PC is not performant and is prone to the single point of failure.
  - 2PC wraps two phases in the same transaction, whereas TC/C separates them into separate transactions.
  - 2PC is executed at the database level, whereas TC/C and Saga are executed at the application level.
  - TC/C is better than Saga when latency requirement is high.
• Event sourcing:
  - The advantage of event sourcing is reproducibility.
  - Only validated commands generate events.
  - Event generation (based on the state and the command) may contain randomness.
  - State update on event must be deterministic.
  - Events are saved as immutable history.
• Command-query responsibility segregation (CQRS):
  - A single state machine for updating the state.
  - Multiple state machines for building read-only views.
• Use mmap to log commands and events on the local disk and to cache recent ones in memory.
• Use LSM tree-based RocksDB as the state store for optimizing write performance.
• Use the Raft consensus algorithm to replicate the event list across multiple machines.

Chapter 13. Stock Exchange

• Clients interact with the stock exchange system via the brokers to
  - Place orders.
  - View executions by order.
  - View market data (L2 order book).
  - Download historical data (candlestick charts) for analysis.
• An order is an inbound instruction, and an execution is an outbound matched result.
• The latency-sensitive trading flow consists of:
  - The client gateway, which provides authentication, rate limiting, validation, etc.
  - The order manager, which evaluates risks and checks users’ wallets.
  - The sequencer, which stamps every inbound order and outbound execution pair with a sequence ID to provide functional determinism.
  - The matching engine, which matches buy and sell orders.
• The market data publisher receives executions from the matching engine and builds (1) order books and (2) candlestick charts.
• The order manager merges incoming orders and outgoing executions into a reporting flow.
• An order book is a list of buy and sell orders for a specific security or financial instrument organized by price level.
• To reduce end-to-end latency of the trading flow:
  - Put everything in a single server to eliminate network hops.
  - Use mmap and shared memory for interprocess communication.
  - Make each application loop single-threaded and pinned to a fixed CPU core.
• Keep a warm matching engine as a fast failover of the hot one.
• Use the Raft protocol to elect a new server when the active one dies.

References:

1. Alex Xu and Sahn Lam. System Design Interview — An Insider’s Guide (Volume 2). Byte Code LLC, 2022.

Devin Z

Software System Design

View list

31 stories
